Rotate Square Screen

Rotate Square Screen combines a rotating cube format with fine-pitch LED options for indoor creative displays. Confirm the mechanical assembly and installation requirements for each project.

Request this series Explore Creative

Rotate Square Screen LED display product

Rotate Square Screen supplier product illustration 2

Product illustrations. Configurations shown may require optional components.

At a glance

Refresh Rate: 3840Hz
IP Rating: IP30

Before requesting a quote

Define the display format and installation

Which format does the project require: a rotating cube, advertising trailer, LED floor, sphere or pole display?
What are the intended dimensions, operating environment and mounting or movement requirements?
Which content mapping, control equipment, service access and project-specific safety checks need to be included?

LED Video Wall Resolution: Calculate the Native Canvas Before You Buy →LED Video Wall Power Consumption: Average, Maximum and Quote Assumptions →

Configuration options

Identify the exact pixel pitch, cabinet format and operating environment when requesting a quotation. Listed options do not mean every combination is interchangeable.

Indoor · P1.86 mmView configuration

Pixel Pitch: P1.86

LED Type: SMD1515

Pixel Density (pixels/m²): 288906

Refresh Rate: 3840Hz

Scan Mode: 1/43

Brightness: ≥600 cd/m²

Grayscale: 16bit

Power Consumption (Average/Maximum): 200/400 W/m²

Maintenance Access: Front

IP Rating: IP30

Contrast: ≥5000：1

Viewing Angle: 360°

Operating Temperature: -20 to 50°C

Input Voltage: AC100~240 50/60HZ

Control: Novastar/Colorlight

Indoor · P2 mmView configuration

Pixel Pitch: P2

LED Type: SMD1515

Pixel Density (pixels/m²): 250000

Refresh Rate: 3840Hz

Scan Mode: 1/20

Brightness: ≥600 cd/m²

Grayscale: 16bit

Power Consumption (Average/Maximum): 200/400 W/m²

Maintenance Access: Front

IP Rating: IP30

Contrast: ≥5000：1

Viewing Angle: 360°

Operating Temperature: -20 to 50°C

Input Voltage: AC100~240 50/60HZ

Control: Novastar/Colorlight

Indoor · P2.5 mmView configuration

Pixel Pitch: P2.5

LED Type: SMD2121

Pixel Density (pixels/m²): 160000

Refresh Rate: 3840Hz

Scan Mode: 1/16

Brightness: ≥600 cd/m²

Grayscale: 16bit

Power Consumption (Average/Maximum): 200/400 W/m²

Maintenance Access: Front

IP Rating: IP30

Contrast: ≥5000：1

Viewing Angle: 360°

Operating Temperature: -20 to 50°C

Input Voltage: AC100~240 50/60HZ

Control: Novastar/Colorlight

Specifications

Pixel Pitch	Indoor P1.86: P1.86; Indoor P2: P2; Indoor P2.5: P2.5
LED Type	Indoor P1.86: SMD1515; Indoor P2: SMD1515; Indoor P2.5: SMD2121
Pixel Density (pixels/m²)	Indoor P1.86: 288906; Indoor P2: 250000; Indoor P2.5: 160000
Refresh Rate	3840Hz
Scan Mode	Indoor P1.86: 1/43; Indoor P2: 1/20; Indoor P2.5: 1/16
Brightness	≥600 cd/m²
Grayscale	16bit
Power Consumption (Average/Maximum)	200/400 W/m²
Maintenance Access	Front
IP Rating	IP30
Contrast	≥5000：1
Viewing Angle	360°
Operating Temperature	-20 to 50°C
Input Voltage	AC100~240 50/60HZ
Control	Novastar/Colorlight

Product details

Supplier illustrations show product features and possible configurations. Brightness, protection ratings and optional assemblies depend on the selected version; use the specifications and confirmed quotation for your order.
